Continuous Casting Machine Price in Pakistan

Continuous Casting Machine Price in Pakistan

Product Description:

(1) R5.25\R6\R8 continuous casting machine, technical characteristics of continuous casting equipment

1. Integral copper tube type strip mold, simple equipment and low cost

2. High frequency and small amplitude leaf spring vibration, the depth of vibration marks is less than 0.2mm

3. Simplified billet guide device, low cost and easy maintenance

4. Five-roller and four-drive tension leveling machine with large tension and leveling force

5. Auxiliary tension leveling machine can perform secondary leveling on the billet in the event of an accident

6. Stainless steel special cutting car, which can cut to length quickly and accurately

7. The surface grinding rate is less than 5%

(2) R5.25\R6\R8 continuous casting machine, process parameters of continuous casting equipment

Model: full arc continuous straightening billet continuous casting machine

Number of streams: 1, 2, 3, 4, 5, 6

Casting machine radius: 6, 8, 10m

Casting billet specifications: Billet: 80*80, 90*90, 100*100, 120*120, 150*150, 180*180, 200*200, 240*240mm

Rectangular blank: (120～200) (240～600)

Working speed: 0.6～1.2 m/min

Annual output: 100,000 to 150,000 tons/flow

Spill rate: ≤0.1%

Continuous pouring time: ≥8h
